מפרט טכני משדר ICM 2066

Transmission channel: Single channel

Carrier Wave Frequency Range: 470-932MHz  (Depend on where you located)

Oscillation mode:hase-locked Loop controlled

RF turning step: 25KHz (Depend on where you located)

Modulation mode: FM Stereo modulation

Transmitter power: ≧50mW，(Depend on where you located)

Modulation level:±40KHz

Frequency responses:40Hz-15KHz

Audio input: XLR and 6.3mm composite socket

Earphone output :6.3mm stereo socket, adjustable volume

Earphone  output impedance:≧16Ω

Dimension (mm):210(L) x 45(H) x 148(D)

Weight（kg）:1.1

מפרט טכני מקלט ICM 2066

Receiving number: UnlimitedOscillation mode: PLL Phase-locked Loop controlled

RF tuning step:25KHz (Depend on where you located)

Modulation mode: FM Stereo modulation

Sensitivity: S/N>80dB base on input 6dBμV

Stereo separation:≧45dB，1KHz

S/N>80dB with input 6dBμV  :40Hz-15KHz

Output socket: 3.5mm stereo earphone socket

Output power 2×50mW以1KHz (THD 3%)

Earphone  output impedance:≧16Ω

Dimension (mm):66(L) x 108(H) x 22(D)
